A drain or siphon is important for the installation of a steam bath. The siphon itself requires a height of around 15 cm. This height must be taken into account if you plan to sink the floor of the bath into the floor. If there is underfloor heating in the bathroom or in the area of the planned steam bath, it must be professionally relocated. This is best done by a heating engineer who has the necessary know-how. As an alternative to relocation, the tub body can also be placed on the prefabricated floor.

To connect the steam bath, water pipes must be prepared on site by the plumbing specialist. The number of connections varies depending on the type of fittings. For the Lotus variant, two connections for hot water and one for cold water are required. For the SteamFit variant, one connection for hot water and two for cold water are required.

The connections for the power supply must also be prepared on site, ideally by an electrician. For our Lotus model, a 230V/16A connection is required. For the SteamFit model, on the other hand, 400V and, depending on the size of the cabin and generator, an additional fuse with 12 to 32A. You can read all the details about the necessary power connections in the respective data sheets of the steam bath models.

This largely depends on the size of the steam cabin or shower. For the Lotus, SteamFit and SteamShower models there are individual restrictions - depending on the steam generator used. The external dimensions to be provided are given in the technical data sheets. In principle, all dimensions are possible for steam rooms. The Lotus model should not exceed 2 m² for optimum steam generation. For the Steam Fit and SteamShower models, a maximum length of 2 m and a maximum width of 1.3 m are recommended so that steam can form and diffuse optimally inside the cabin.

Design options are available for the colours of the plastic panels used. The large-format panels made of WSP plastic can be finished in any RAL/NCS colour. For even more highlights, a glitter effect "Stratos Diamondsplitter" is also possible. Alternatively, your own image motifs are possible; the prerequisite for the application is a sufficiently large resolution of at least 72 dpi in real size.

The Lotus and SteamFit models are maintenance-free, but regular descaling is still recommended. The frequency is determined by the hardness of the water. When this should take place is determined by the technician after determining the water hardness, so that you are informed by the system in good time about the impending descaling. With the Lotus model, you can easily do the descaling yourself, with the SteamFit model, the descaling service is recommended by a specialist due to more complex technology.

Küng steam baths are usually supplied complete with cabin, sealing and the necessary technology. This means you get everything from a single source and always have a competent contact person for your steam bath. The Lotus and SteamFit steam bath models can be installed on an on-site tiled floor or shower floor.

To avoid too much humidity in the bathroom, it is recommended to install it in a room that has a window for ventilation. If this is missing, a technical exhaust air solution can be a good alternative. In the Lotus model, the cabin has an integrated ventilation system which, with a cabin size of around 2 m² and an average steam duration of 60 minutes, does not produce a quantity of water vapour that is harmful to the building fabric.

For the use of steam baths, there are no rigid recommendations for temperature, humidity or length of stay. The ideal temperature can be different for everyone. Recommended steam bath temperatures are in the range of 35 to 45°, depending on what you find comfortable. You can stay in the steam bath for at least 20 to 30 minutes and a maximum of 60 minutes. In the Lotus model, the running time is limited to 60 minutes, but after expiry, a new steam bath cycle can be started directly. With a SteamFit generator, the default setting for the running time is 3h.

Yes, of course, the Lotus and SteamFit steam baths are ideal for using essences and essential oils. Depending on the desired effect, there are different essences that you can order, for example, in the Küng shop. In the Lotus natural herbal steam bath, natural herbal mixtures can also be used as an alternative to our essences.

It takes about 10 to 15 minutes for the first steam to form and the necessary heat to build up in the cabin.

The insulation and isolation play a decisive role in the energy consumption of the steam bath. The more the steam room is insulated, the lower the power consumption. An average stay in the steam bath lasts about 20 minutes, with three passes it comes to about one hour. The power consumption depends on the size of the steam room. Small cabins with 8.5 kW power cost only 55 CHF (0.20 CHF kWh) for about 32 hours of use per year, while larger cabins with 12.5 kW cost about 80 CHF per year. The annual electricity consumption for a Lotus cabin is about 25 CHF and for a steam shower with SteamFit generator 40 CHF.

With five to ten liters per steam cycle, water consumption is minimal. The power of the heating elements is 1.5 to 3 kW. By way of comparison, a kettle has an output of around 2 kW.
